If you would like to learn more about Rotary Sliding Vane Blower, please feel free to contact us and we will do our to assist you.
Rotary Sliding Vane Blower
Motor: 0.75kw-4
Frequency: 50HZ/60HZ
Rotating Spped: 500rpm
Application: water treatment industry for aeration
Flow capacity: 0.59-0.66m3/min
Pressure: up to 49kpa
Diameter of blower pulley:12 inch
Diameter of motor pulley: 4 inch
Noise: less than 60dB
Weight: approx. 100kg
86-0513-68903288
13906298796@139.com
Product Description
The rotary blower can supply air pressure range from 0.1kgf/cm2-0.5kgf/cm2. It mainly consists of the following parts motor, safety valve, pressure gauge, check valve, oil lens, oil filter, drip nozzle, etc.
The rotor eccentrically assembled in the chamber rotates along with four vanes, thus forming air suction, compression, and discharging processes. The heat is produced by the friction of the vane and chamber. Thus lubrication oil should be added from the drip nozzle to reduce heating and noise caused by friction. The oil film is formed during the process to maintain the seal performance. The oil lubrication system works automatically by the pressure difference formed during the on-load working stage. So it is forbidden to operate the blower without load.
Product Characteristics And Application
|
Nantong Rongheng Environment Equipment Co.,Ltd offers a wide-ranging reliable blower solutions with greater excellence and competence which are used in various applications in all type of industries. Our blowers are largely used for applications like - waste and sewage water treatments, effluent treatment, aquaculture, cement conveying, paper plants, electroplating and so on. The fineness in quality coupled with energy efficiency is the key that differentiates us from others to maintain leadership in global blower industry.  |
 |
| Basic Info. | |||
| Model NO. | HD-401S | Color | Yellow |
| Material | Iron | Warranty | 12 Months |
| Usage | Water Treatment Aeration | Trademark | RH |
| Flow Direction | Cross Flow | Transport Package | Standard Wooden Package |
| Pressure | Low Pressure | Specification | HD-401S |
| Certification | ISO, CCC | Origin | China |
| Weight | 90-180kg | HS Code | 841459 |
| Application | Water Treatment Aeration | ||
